Sutton Tools Impact Taps are specifically developed for use with the high-torque output of an impact driver. Suitable for steel, aluminum, brass, cast iron, plastic, and nylon. Impact taps are ideal for routine maintenance, repair work and for rethreading where high accuracy and tolerance thread is not critical. Tapping with an impact driver is approximately 20 times faster than hand tapping – only three seconds to tap a hole!
Not suitable for precision, safety or critical threads. For tapping up to 1-1/2 x diameter.

20X faster – 3 seconds to tap a hole
1/4" hex shank suits impact drivers
Straight Flutes suitable for through-hole tapping up to 1-1/2 x diameter
Intermediate lead suitable for through holes or blind holes where the thread does not need to go right to the bottom of the hole
Made from tungsten chrome alloy
Bright finish for general purpose applications, non-ferrous metals & plastics

Specifications

Designation: N
Finish: Brt
Shank Form: A
Type: Straight Flute
Thread Form: M
Lead: Intermediate
Material: TCA
Max Cut Depth: 1.5xD
x: als
Standard: Sutton
Nut Tolerance: ISO 2 / 6H
Drill Ø: 4.2
Pitch: 0.8
Size: M5
